Model

 ISS300F

 System Specification:



 Rated Output Power

 300W

 Solar Panel Power

 18V 100W(50W*2)

 Solar Panel Charging Time

 6 hours effective sunlight

 Battery Capacity

 12V 33AH Gel battery

 AC Output

 AC 110V/220V/230V  50Hz/60Hz

 AC Output Waveform

 Modified sine wave

 AC Output Socket

 English \ German \ French \ Australian \ American \ Universal

 DC Output（USB Interface）

 5V (500mA)

 Peak Inverter Efficiency

 85%

 Overload Protection

 Yes

 Under-voltage Alarm

 Yes

 Overheat Protection

 Yes

 Short-circuit Protection

 Yes

 Battery Power Indicator

 Yes

 External Battery Charger

 Yes

 External Battery

 Yes(12V Gel)

 External Battery Capacity

 Based on actual needs and to be prepared by customer, the  capacity of charging is more than or equivalent to the sum capacity of both our product and external battery.

 Accessories

 PV connectors  2 pairs (Optional)

 External battery cables  2pcs (Optional)

 Certificate

 CE & RoHS

 Mechanical Data:



 Dimensions of System Box(mm)

 L375*W150*H320

 Net Weight of System Box(kg)

 16.4

 Appearance Color

 White + Green

 Dimensions of Solar Panel (mm)

 L640*W530*H30

 Net Weight of Solar Panel (kg)

 4.5

 Dimensions of Battery (mm)

 L195*W130*H155 (Total H180)

 Net Weight of Battery (kg)

 10.5
